This is done automatically by the software when the carved area is deeper than the maximum cutting depth of the tool.
The Raised Prism machining strategy is prefect for cutting high quality raised lettering and shapes on signs for restaurants, hotels and bars etc.
This function generates an efficient and smooth toolpath to cut 3D shapes such as mouldings, arches and frames that have a constant cross-section.
The shape is specified by selecting two vectors; the first will represent the Drive Curve of the shape and the second defines the Cross Section that will in effect be extruded along the Drive Curve to create the swept shape when machined.
The Moulding Toolpath function allows you to specify two tools, one to in effect "Rough" out the majority of material with a larger tool and then the other to do the "Finishing".
The Moulding Toolpath has some clever options to further improve finish and efficiency. For the "Finish" tool you can opt to "Vary Stepover", this can be used to improve finish on shapes that have a lot of steep angles or curves on the cross-section.
For the "Rough" tool you can choose to have it pre-finish any flat horizontal regions on the cross section, which are common on a lot of Moulding shapes.
Using this option also allows you to avoid creating a "Finish" toolpath in those flat areas further increasing time-savings when machining.
When using this toolpath the software drives the tool along the center of the vector giving you control over the way the tool ramps into the start and end of each selected object.
This has many interesting applications outside of just the standard uses you would expect for this type of operation.
Perfect for:. Textured panels are often specified by interior designers and architects and textures are also a very useful option for creating backgrounds on dimensional signs.
Vectric has a unique approach to generate unique 'hand carved' looking textures which still machine extremely efficiently. Once you specify a tool typically a pointed or round profile then you have various settings you can set to create the characteristics of your texture toolpath.
To give these textures a more natural and less machine made look you can set different levels of randomness. The toolpath will replicate the same type of move that would be made by someone using a chisel to carve overlapping strokes into the material.
Creating this as a toolpath move rather than as a 3D model will minimize the hand-finishing and also the machining time required to cut this.
Textures can also be 'trimmed' to a vector boundary allowing the creation of this type of finish in a background area of a job. This is a look very popular with sign makers using Vectric software.
The auto-inlay toolpath options calculate profile cut-out and pocketing toolpaths for parts that need to be assembled to make inlays and inserts.
There are two toolpaths which are typically used to machine the 3D parts of a job. The areas that these toolpaths cut is governed by selecting one of the three machining limit boundary options, model boundary, material boundary or selected vector s.
Model boundary will use the outer silhouette of the composite model all the 3D components visible in the 3D View at the time of calculation.
This means there is no need to create a vector boundary around them for these operations. Material boundary will create a toolpath that completely fills the entire job area.
Selected vector s will use any vectors you have selected in the 2D view as the boundary for the toolpath. To remove the majority of unwanted stock as quickly as possible most jobs require a 3D roughing toolpath to be calculated.
There are two roughing strategies available z-level and 3D raster each of these has advantages depending on the type of shape being cut.
The toolpath also has an option to specify an allowance to leave a skin of protective material on the part for the finish cut to clean up.
The tool parameters let you balance the quality of the surface finish with how long the part will take to cut. Depending on the shape of the part there is a choice of raster and offset cutting strategies.
Detailed regions can be machined selectively using smaller cutters to ensure the finest of detail on a 3D project is accurately machined.
This allows text or other shapes that follow the 3D contours of the part to be efficiently machined onto the 3D component model.
One of the most important productivity tools available in the software is the realistic 3D toolpath preview support.
The results of each individual or the combination of all the toolpaths can be previewed cutting into a 3D preview model. This means that whether your job is a simple toolpath with one tool, or created from a complex combination of tools and strategies at different levels you can be sure that when the job is cut, it is right first time.
As well as showing that the toolpaths are correct, the high quality rendering and ability to use real world material textures and fill colors, and even preview lithophanes, is a valuable sales tool.
Using the simulation you can create customer proofs and evaluate design options without actually having to cut anything! This makes it easier when working on a job that only has vectors with 2D and 2.
To help estimate how long toolpaths will take to cut the software will calculate a time based on the length of the toolpath and the specified feeds and speeds that have been entered for the selected tool.
This can be tweaked by the operator by editing the 'scale factor' so over time a value can be optimized based on actual machine performance to ensure the estimate is as close as possible to the actual cutting time.
Using the Toolpath Tiling options it is possible to machine objects and designs that are many times larger than the available area of your CNC machine bed.
This process is also invaluable if the maximum sizes of your material pieces are limited. In both cases, a much larger project can still be machined by breaking the toolpath down into manageable tiles or strips, each of which can fit within the machineable area of your CNC machine, or on the available material blocks.
Once cut, the tiles can then be re-assembled to form the finished piece. Toolpath templates allow you to improve the efficiency of your production processes by saving the complete toolpath settings for common operations.
These settings can then be re-used at any time on different design geometry. Frequently used strategies and tooling can thus be applied to similar jobs, quickly and easily.
The software allows you to add your own custom tools shapes to the tool library and generate toolpaths and simulate the finished result!
Now you can simulate the effects of complex roman ogee cutters, round over bits and any other custom tool shape you desire.
Simply draw the tool profile using the vector drawing tools or import the profile from the manufacturer and you can add your custom tool to the list.
In the tool database you can specify feed rates, spindle speeds, cutting depths etc. Wrapped Rotary Axis Toolpath postprocessing allows all toolpaths created in the software to be saved and run on CNC machines fitted with rotary axis or rotary indexer setups.
These setup functions also allow you to specify your rotary part setup and view the wrapped results in the 3D view. This function can be used for designing and cutting projects such as fluted columns and barley twists or engraving text onto round projects.
Note: This functionality wraps standard 3 axis toolpaths around a cylindrical axis, substituting one of the linear axis to drive the rotation of the block of material while it is being cut.
Production Plate Engraving lets you merge text lists into templates for badges and industrial plates.
It can be used to merge CSV and text based lists using variables that can automatically scale to fit a pre-made design layout. Quick Engrave can be used to create toolpaths for Diamond drag tooling.
This is typically used for marking engraved products such as gifts, awards, plaques, badges, pens, trophies etc. The create merged toolpath function allows you to combine toolpaths that use the same tool into a single, new, toolpath that is generally more efficient than cutting the constituent toolpaths independently.
This can be particularly useful if you want a complete individual part to be cut before the CNC moves onto the next piece as it can merge the toolpaths into individual components.
Similarly to the area copy tool, this toolpath allows you to duplicate one or more toolpaths its children as a block, based on the dimensions you enter in its properties.
The create set-up job sheet command allows you to create a summary sheet that details all the important information you will need at your CNC machine when you come to run the toolpaths.
This can be used as a reference to ensure you have the setup correct, have loaded the correct tool etc.
It can also be used to archive with an old job as a quick reference file to see what the job the looked like and the machining that was involved for that project.
You can also edit this to change the logo to an image of your own choice, adjust the header, footer and border colours and even customize which sections of information to include.
Use the PhotoVCarving toolpath strategy to convert photographs and images into toolpaths producing stylised engraved designs.
The created toolpaths engrave a series of lines at different depths to produce the desired image. The software has a built in tool database to make cutter management quick and easy.
Tools can be organized in any way that suits your workflow. There is automatic support for machine management and material management. Tools can be filtered for your current material and machine settings, which makes selecting the right tool for the job simple.
The tool database contains a powerful tool naming system. This allows you to have consistent tool names, and for those tool names to match the properties of your cutter.
The thread milling toolpath enables you to machine holes for standard size screws in metals, woods, and acrylics, and is also useful for the creation of decorative wood fasteners.
The thread milling toolpath has the option to create both internal and external threads, for example if you wanted to create a cavity to screw something into or if you wanted to create an exterior thread on something like a bolt!
The chamfer toolpath allows you to easily create chamfers using v-bits or ball nose tools to create decorative edges and is also a great way to create counter-sunk holes.
Toolpaths generated in PhotoVCarve can be imported into the software to combine with other toolpath types.
Multiple PhotoVCarve projects can be imported and positioned, where additional elements can then be added and machined.
All of the toolpaths can then be previewed and saved from the software. The contents of either the 2D or 3D view can now be printed using the Print command on the File menu.
Simply select the view you wish to print 2D or 3D and then click the Print command. The standard Windows printer dialog allows you to select the printer and adjust its properties.
When the OK button in this dialog is clicked, the view will be printed. The Print Preview command on the File menu allows you to check the layout of your page before you print.
The printed view is always scaled to exactly fit the currently selected page size including allowance for margins.
Drawings are not, therefore, printed at actual size and are not printed across multiple pages. We give you access to the online clipart that comes free with your purchase.
The software comes with previews of the clipart you're entitled to in the clipart tab so that you can see all of the options available to you and download the items of interest,.
In order to get the latest entitlements, click the refresh button. To import the clipart from the clipart tab into your job, simply drag and drop your desired model onto your part.
Windows explorer can make use of these thumbnails to show you a preview of each file when you browse a folder. The software also supports Windows drag and drop functionality to quickly add pieces of 2D or 3D clipart into an existing model directly from windows explorer.
With windows explorer open, simply click and drag the 3D clipart thumbnail of the file you want from the explorer window into the 2D or 3D View.
The selected file will be imported automatically and displayed in the software. These are split into sections beginning with getting started projects to let you see the process to produce a complete part and start to understand the general workflow.
Then there are videos to cover each area of use within the program. The videos are designed to take you step by step through different types of projects to explain the key methods you will use in the software and to demonstrate these on real-world examples.
You can just watch and absorb the contents or follow along pausing where necessary to complete a task. In addition to learning how to use the program the videos include tips and tricks for better use of the software.
The result of each project along with the Clip Art provides a library of parts which can be machined to create sample files to improve your CNC skills or help you to demonstrate your capabilities to potential customers.
One of the most important features of any program is not within the program itself. It is the support and resources available when you are learning the program or when you have a question about how something works or even a suggestion for a new feature.
The FAQ pages have searchable general and software specific questions and answers. The forum lets users ask questions and discuss techniques related to CNC and the software.
In addition to direct input from Vectric, there are a large number of enthusiastic users who are always willing to help on any topic associated with CNC machining.
Another very interesting section of the forum is the gallery area where users can post images of projects they have done using Vectric software.
Please take a look, there are some very nice examples of work on there. The new versions have installers for both bit and bit computers.
The installer will detect and install the appropriate version for your machine. Gadgets are small programs that add additional functionality to Vectric products.
They can be used to add new features to the software or automate common sequences of tasks. Examples include adding the ability to cut dovetail style joints with a standard end mill and applying toolpath templates to every sheet in a nested job followed by automatically post-processing and saving the files for your machine tool.
You can also associate specific key combinations to these to very quickly access them as part of your standard work-flow. We have only been able to give a brief overview of some of software capabilities here.
To really understand the speed, ease of use and full scope of what the program can do then please download the trial version and try it for yourself.
The video tutorials will get you up and running quickly and the trial version is supplied with a number of standard demonstration files which you can scale and cut on your own machine using your own tooling to verify the quality of the toolpaths from the software and compatibility with your machine.
In addition to the standard demonstration files we supply, you can load any of your own data files and preview them using the standard toolpath simulation capabilities of the program.
Finally, if you have reached this far, we'd like to thank you for your interest in Vectric software and encourage you to Integrated Help.
Help for all forms can now be found using the handy integrated help functionality. Click on the question mark icon on the top of each form to get the help for that specific function.
Products Aspire. Aspire has a number a modelling tools, use the sculpting tools like virtual clay. Aspire has a variety of tools to create 3D textures from automated repeating patterns.
Aspires powerful 3D sculpting tools provide total flexibility when modifying designs. Aspire includes 2D and 3D clipart files that can be used as is, in your own projects.
Why Choose Aspire? Comprehensive Set of 3D Modeling Tools Enable you to explore your creativity and create your own relief models for 3D machining.
Extensive set of Model Editing Tools An extensive set of editing tools to help you manipulate 3D data. Interactive Model Sculpting Mode Powerful sculpting tools mean models can be manipulated like a virtual piece of clay.
I would like to be kept up to date with information about new products and services. Buy Aspire. Key Strengths of Aspire Aspire's single interface for 3D component design and machining makes it easy and logical to draw and build 3D component models, plus calculate combinations of 2D and 3D toolpaths to machine high quality projects.
The emphasis on ease of use not only includes the interface and work-flow of the software but has also been carried through into the training materials.
Aspire ships with over 90 hours of tutorials based on real-world examples that cover all aspects of using the program.
The videos are accompanied by the associated files that allow users to watch and work through the training materials at their own pace.
Aspire has a unique interactive approach to assembling 3D component models that makes it easy to change the shape and characterisitcs of individual parts of the job and build up complex designs using simple sets of 3D shapes.
Flexible design tools allow components to be edited - moved, scaled, resized, rotated, tilted, faded and distorted at any time without having to recreate the component.
Changes to shape, height or inclination are instantly updated in the 3D view showing exactly what the final result will look like. This takes the guess-work out of creating high quality models.
Aspire lets you dynamically edit 3D components using the mouse as well as giving you the ability to enter specific values to manipulate the part.
The 3D model preview allows 3D components to be displayed in different material types or colors to produce realistic results for customers quotations, web site content or including in your marketing material etc.
Aspire's ability create or edit 2D and 3D data coupled with the comprehensive set of toolpath strategies gives you the ability to choose the most efficient ways to make 2D parts, 3D carvings or jobs which combine both with your CNC.
Offer your customer a range of cost options from budget 2D designs to higher value 3D products. Save time and money by re-using previously created 2D vectors or 3D models as Clip Art in other jobs Use the large range of tutorials to learn new skills for use on your CNC and to create samples to help demonstrate and sell your capabilities.
Not only increase your skill-set and productivity but also your job satisfaction and enjoyment of using your CNC Router. Click the buttons below to view more about specific features.
Machine Parts on Two Sides. Wrapped Rotary Machining. Other features. Two-Sided Machining This adds the ability to create double-sided projects in the same session.
In the 3D view, you will see the entire merged model as if it was simulated. Machine Wrapped Rotary Parts.
Wrapped Rotary Machining Enables the use of a rotary axis also called a 4th axis or indexer. Vector Unwrapping The vector unwrapper tool converts a vector into another vector suitable for using with the two-rail sweep tool to create rotary models from a desired cross section.
Spiral Toolpaths In order to create a toolpath that wraps around multiple times, one can create a long vector at a certain angle.
Model Import into Rotary Project The software has the ability to import full 3D models from third party software for unwrapping in a rotary job, where you can position and orient the model in a rotary view.
Vector Shape Creation The software has a comprehensive set of drawing tools to let you easily create vectors from scratch or add to imported data.
Image Tracing Vectorization Image tracing also known as vectorization allows you to take an imported image such as a scanned drawing, graphic design or photo and to convert colors in that to vector outlines.
Advanced Text Tools The 'advanced text' tools let you access true type or open type fonts on your PC to create text outlines for your design.
Basic Dimensioning The dimensioning tools allows you to create a variety of different types of measurements on your drawing.
Vector Layout In addition to the editing tools the software also has tools to let you layout parts either in a rectangular array to create a grid of objects or in a circular array to create symmetrical layouts around a center point.
True Shape Nesting True Shape Nesting lets you automatically arrange and fit vector shapes into your material size or user definable area, to get optimal material usage and minimum wastage.
Layer Management The Layers are a very efficient way to keep your 2D data organized, one of the main uses is to allow you to temporarily hide data you were not currently working with.
Trim Objects to a Vector Boundary The trim tool allows you to simultaneously trim all the objects inside or outside of a selected area.
Create Vector Texture Repeating vector patterns can be quickly created using the 'create vector texture' tool. Quick Keys This allows you to add more precision to your shape creation and editing process more easily by allowing typed values while creating geometry.
Vector Validator The Vector Validator is intended to help find issues with contours after file imports that are stopping tool-path creation such as overlapping contours or intersections.
Create Shapes from Vector Outlines The create shape modeling function Instantly adds 3D shape to a closed vector outline based on either a curved, angular.
Two Rail Sweep Sweep along two vector rails to model 3D shapes based on one or more cross section shapes.
Options for this tool include: Controlling the direction of the drive rails Scaling to a specific height Dynamically dragging or snapping the exact position of each cross section to define the shape you want Link corresponding nodes on matching drive rails to make mitre-style corners.
Filling the middle of a closed rail to create panel shapes. Extrude and Weave Extrude and weave allows you to use one or more vectors as drive rails and extrude either vector cross sections or existing 3D components along them.
Create Texture Area This feature lets you create a repeating pattern or texture. The pattern dynamically updates as you make changes, you can even adjust the size and position of your original "tile" at any time 40 models have been created specifically for use with this new tool and are supplied with the software as part of the included clip art.
This function can also be used to make high quality lithophanes back lit machined photos. Mirror Mode Components This feature allows you to define a component level so that it mirrors all of its components in a certain way, based on the mirror type.
Offset Model The Offset model tool creates a 3D offset of the composite model. Any model you create in Aspire can be saved as a piece of clipart for use in other projects.
Clipart Browser The clipart tab provides quick and convenient access to Vectric files containing 3D components or 2D vector artwork. Level Clipping The level clipping mode makes it easy to constrain the model you are creating to a chosen boundary.
Material Setup Referencing the software to how your CNC will be setup is one of the most important elements of the process.
Fast and Efficient Pocketing — optimizes use of multiple tools The pocket toolpath makes machining the material away from inside a vector shape efficient and easy to achieve.
Helical Arc Support Output helical arcs in a way that your machine understands. Drilling Whether you are drilling a single hole or hundreds, just select the vectors representing the holes and the software will drill the center of each vector to the specified depth.
Precision V-Carving V-Carving uses a constant angled cutter that's moved at flowing variable depth to create a 3D carved effect on the job, similar to the way a craftsman would work by hand.
Raised Prism Machining The Raised Prism machining strategy is prefect for cutting high quality raised lettering and shapes on signs for restaurants, hotels and bars etc.
Raised Prism carving uses the side angle of V cutters to rapidly form angled sides around the selected shapes.
Automatically calculates the material thickness required to create a full prism based on the job size and cutter angle. Calculates multiple Z passes when rough machining is required to remove material from around the prism shape.
Typically used when cutting raised lettering on signs. Moulding Toolpath This function generates an efficient and smooth toolpath to cut 3D shapes such as mouldings, arches and frames that have a constant cross-section.
Perfect for: Woodworking and solid surface machining. Flutes on columns and fireplaces Drainage grooves on kitchen sink and shower units Options for ramping in and out to create unique decorative results.
Efficient Texture Toolpath Textured panels are often specified by interior designers and architects and textures are also a very useful option for creating backgrounds on dimensional signs.
Auto-inlay Toolpaths The auto-inlay toolpath options calculate profile cut-out and pocketing toolpaths for parts that need to be assembled to make inlays and inserts.
Automatic cutter radius compensation on corner regions to ensure male shapes will fit into female pockets or cavities Allowance option to ensure a sufficient 'gap' is created to allow parts to fit together 4 different Inlay options that are designed to make machining inlays very simple and straightforward straight, stepped, pocket and hole Ideal toolpath option for sign makers, woodworkers, plastic and solid surface fabricators who need to cut parts that fit closely together.
VCarve or engrave at constant depth onto a 3D surface Pocket, profile, drill and texture onto the 3D model. High Quality Toolpath Preview One of the most important productivity tools available in the software is the realistic 3D toolpath preview support.
Estimated Machining Times To help estimate how long toolpaths will take to cut the software will calculate a time based on the length of the toolpath and the specified feeds and speeds that have been entered for the selected tool.
Toolpath Tiling — Divides toolpaths to fit material or machine limits Using the Toolpath Tiling options it is possible to machine objects and designs that are many times larger than the available area of your CNC machine bed.
Toolpath Templates Toolpath templates allow you to improve the efficiency of your production processes by saving the complete toolpath settings for common operations.
Form Tools - custom shaped cutter profiles The software allows you to add your own custom tools shapes to the tool library and generate toolpaths and simulate the finished result!
Wrapped Rotary Axis Toolpaths Wrapped Rotary Axis Toolpath postprocessing allows all toolpaths created in the software to be saved and run on CNC machines fitted with rotary axis or rotary indexer setups.
Production Plate Engraving Production Plate Engraving lets you merge text lists into templates for badges and industrial plates.
Create Merged Toolpath The create merged toolpath function allows you to combine toolpaths that use the same tool into a single, new, toolpath that is generally more efficient than cutting the constituent toolpaths independently.
Array Copy Toolpath Similarly to the area copy tool, this toolpath allows you to duplicate one or more toolpaths its children as a block, based on the dimensions you enter in its properties.
Create Job Sheet The create set-up job sheet command allows you to create a summary sheet that details all the important information you will need at your CNC machine when you come to run the toolpaths.
Photo VCarving Toolpath Strategy Use the PhotoVCarving toolpath strategy to convert photographs and images into toolpaths producing stylised engraved designs.
Try Before You Buy Try out all the features with no obligation to buy. Test Machine Compatibility There are a variety of free projects available to you to cut from within the free trial.
Unlimited Trial No limits to how long you can use the trial software. No Sign-up Required You will not need to enter your card details or personal information.
Buy Aspire. Get started by following along to some video tutorials. Shell Sign. Snowflakes Shelter 2. Hanging Planter.As well as a single Z plunge you also have the option to activate peck drilling Prior Deutsch, which drills to a specified depth, retracts the tool to clear the chips, drills down to the next step, retracts the tool and so on until the required finish depth is reached. The tool parameters Zaandvort you balance Spielen.Net quality of the surface finish with how long the part will take to cut. Buy Aspire. Help for all forms can now be found using the handy integrated help functionality. Just select all the vectors defining the shapes you want to cut and the program will sort the vectors to identify islands automatically and offset the boundaries for the selected tool radius. There are also editing Beste Spielothek in Nohra finden for fitting text to a curve and interactive text arcing Pantiesparadise De spacing kerning where the text maintains formatting, allowing you to easily make edits after the text has been created. It is used for some of the simplest and also Spielsucht Kindern ErklГ¤rt most complex things you may do with Beste Spielothek in Ranklleithen finden CNC. The toolpath also has an option to specify an allowance to leave a skin of protective material on the part for the finish Tiger Games to clean up. Finally, if you have reached this far, Wie Wird SchГ¤rfe GemeГџen like to thank you for your interest in Vectric software and encourage you to The software has a comprehensive set of drawing tools to let you easily create vectors from scratch or add to imported data. Vector shapes can also be pasted along the path of another vector by specifying the distance between each copy or just fitting a specific number on the guiding object. As you make changes to a component the 3D model will update to Showdown you instantly the effects of your choices making it easy to iterate through different design options. Not only can you import full 3D models for unwrapping the software also allows for the importing Beste Spielothek in Zinsegg finden "Flat 3D" models Beste Spielothek in Kloster Indersdorf finden style models that you can position and simulate before cutting. Shelter 2. The create shape modeling function Instantly adds 3D shape to a closed vector outline based on either a curved, angular. Vectors Beste Spielothek in Schweinkofen finden be easily scaled, moved, mirrored, distorted, grouped, welded, trimmed, filleted, extended, offset, smoothed and joined together. V-Carving uses a constant angled cutter that's moved at flowing variable Eurojackpot Preise to create a 3D carved effect on the job, similar to the way a craftsman would work by hand. Windows explorer can make use of these thumbnails to show you a preview of each file when you browse a folder. Toolpath Templates Toolpath templates allow you to improve the efficiency of your Wa-Online processes by saving the complete toolpath settings for common Aspire Deutsch.
